ASCO 8290B010 - Angle Body Piston Valve - Standard Voltage: 2-Way, Normally Closed, 1 in Pipe Size, Bronze Body, PTFE Seal

The ASCO 8290B010 Series 290 consists of 2-way direct acting valves in normally closed position constructions. Built for demanding applications, these valves come in a straight-through body design made of bronze. The Series 290 is suitable for the following applications: • General Service (air, inert gas, water, oil, light slurries) • Steam and Hot Water • Auxiliary fluids within the food and beverage process (suffix “FB”)

1" NPT 2 way NC Piston Valve, Entry Under Disc, 63 mm Operator, Bronze Body, 1" Orifice, 19 Cv, 0 PSI Min, 150 PSI Max, 366F Max
