Product Details
ASCO 8290A394 - Angle Body Piston Valve -Standard Voltage: 2-Way, Normally Closed, 3/4 in. Pipe Size, Stainless Steel Body, PTFE Seal
The ASCO 8290A394 consists of 2-way direct acting valves in normally closed position constructions. Built for demanding applications, these valves come in a straight-through body design made of stainless steel.
3/4" NPT 2 way NC Piston Valve, Entry Under Disc, 50 mm Operator, Bronze Body, 3/4" Orifice, 11 Cv, 0 PSI Min, 150 PSI Max, 366F Max
ASCO 8290A394 - Angle Body Piston Valve -Standard Voltage: 2-Way, Normally Closed, 3/4 in. Pipe Size, Stainless Steel Body, PTFE Seal
The ASCO 8290A394 consists of 2-way direct acting valves in normally closed position constructions. Built for demanding applications, these valves come in a straight-through body design made of stainless steel.
3/4" NPT 2 way NC Piston Valve, Entry Under Disc, 50 mm Operator, Bronze Body, 3/4" Orifice, 11 Cv, 0 PSI Min, 150 PSI Max, 366F Max
| Specifications | |
|---|---|
Manufacturer Part Number |
8290A394
|
Body Material |
Stainless Steel
|
Operator Size (Inches) |
50 mm
|
Operating Mode |
Normally Closed
|
Media Entry Point |
Under the Disc
|
Pipe Size (Inches) |
3/4
|
Orifice Size (Inches) |
3/4
|
Cv Flow (On-Off) |
11
|
Cv Flow (Prop.) |
8.3
|
Operating Pressure Differential Minimum PSI |
0
|
Operating Pressure Differential (Fluids) PSI |
150
|
Operating Pressure Differential (Steam) PSI |
150
|
Max Fluid Temp. |
366
|
Pilot Pressure Range PSI |
60 / 150
|
Shipping Weight |
2.9
|
ASCO 8290A394 - Angle Body Piston Valve
- Regular price
- $490.95
- Sale price
- $490.95
